Quadra-Fire SANTA FE - D. External Standard Flue Kit

Page30
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
D.
Each 51 External Standard Flue Kit contains:-
ytitnauQnoitpircseDoN traP
1 Galvanised outer liner
ø100mm x 900mm long
2 Stainless steel inner liner
ø75mm x 900mm long
5 Inner/outer ue liner spacer
6w Wall thimble – 2 pieces
ø102mm holes
6s Sot thimble ø107mm hole
7w Wall decor plate
ø102mm hole – white
8 Rain cap 75mm
9 Rain Cap 100mm
26 Lined T-adaptor
This ue kit may be used in new and replacement
applications with the ue penetrating the wall behind
the re, running vertically up an outside wall and
penetrating the sot. The overall height of the f lue is
3.6m. All visible ue has a galvanised nish, and can be
powdercoated on request. Kit is supplied in a carton.
Note: The Davin 51 External Standard Flue
Kit complies with AS/NZS 2918:2001 as per
Applied Research Test Report 05/1185, dated
15 September 2005.
All res must be installed by a qualied
installer as per the manufacturer’s
instructions and AS/NZS2918:2001.
Heat-resistant
oor protector
Seismic restraint
(to be tted)
600mm from
roof penetration
50mm
(minimum)
150mm
(minimum)
External Standard Flue Kit51
4
4
2
1
1
1
1
1
1
To order :December 2006 Telephone 0800 765 431. Fax 64 3 341 8057 info@switchenergy.co.nz www.switchenergy.co.nz
Drawing representative only - not to scale.
Note: The Davin 51 External Standard Flue
Kit complies with AS/NZS 2918:2001 as per
Applied Research Test Report 05/1185, dated
15 September 2005.
as per the manufacturer’s instructions and AS/
NZS2918:2001.
