Page28
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
7
Flueing Information
A. Chimney and Exhaust Connection
Theuemustbeinstalledbyasuitablyqualiedpersonin
accordancewithAS/NZS2918:2001andthemanufactures
instructions.TheSANTAFEpelletrerangeuseafan
poweredexhaustsystemwithaslightlynegativepressure
inthecombustionchamberandaslightlypositivepressure
intheue.
Fluepartsneedtobe
1. Combustionandcondensationproof(stainless
steel)
2. Havenorestrictionsordraftadjustmentde-
vices
3. Must be suitably insulated where they are
outsidetheroomthereislocated
4. Havethecorrectclearancesfromcombustible
materials
5. FreestandingmodelsmusthaveaTadapter
/cleanoutattheconnectiontothere.
6. INSTALLFLUEATCLEARANCESSPECIFIEDBYTHE
FLUEMANUFACTURER.
7. Secure flue system to the appliance with
atleastthree (3) screws/rivets per the pipe
manufacturer’sinstructions.Alsosecureall
connector pipe joints with at least three (3)
screws/rivetsthrougheachjoint.
8. DONOTINSTALLAFLUEDAMPERINTHE
EXHAUST VENTING SYSTEM OF THIS
UNIT.
9. DONOTCONNECTTHISUNITTOACHIM-
NEYFLUE SERVINGANOTHERAPPLI-
ANCE.
SwitchrecommendstheuseofDavinukitsasoutlinedon
page29andpage30.Thesehavebeentestedand
approvedforusewiththeSANTAFErangeofresifyou
intendtouseadifferentuekityouwillneedtoconsultwith
yourlocalcouncil
NOTE:Sealpipejointswithhightemperaturesilicone, or
equivalent,(250°Cminimumratedonly).Donotputsealant
insideofpipe.
VentsurfacesgetHOT,cancauseburnsif
touched.Non-combustibleshieldingorguards
mayberequired.
WARNING
NOTE:
Illustrations reect typical installations and are
FOR DESIGN PURPOSES ONLY.
Illustrations/diagrams are not drawn to scale.
Actual installation may vary due to individual
design preference.
B. Outside Air Kit Instructions
TherearetwoOutsideAirKitsthatwillworkwiththis
appliance.Onekit,811-0872usesa2inchexhose
(included)anduseshoseclampstosecurethehose.The
otherkit,OAK-3,usesa3inchexhose(notincluded)and
useswiretiestosecurethehose.
Parts Included in 2 inch Kit 811-0872:
1pieceof2
inchx3ft.exhose,2hoseclamps,1collarassembly,1
terminationcapassembly,trimring,1intakeairchannel,
fasteners(Discardtheairintakechannel,itisnotneededfor
thisappliance.
Parts Included in 3 inch Kit OAK-3: 2wireties,1
collarassembly,1terminationcapassembly,1trimring,
fasteners.
Tools Needed:
PhillipsHeadscrewdriver;wirecutters;
holesaworjigsaw,andthelengthofexhoseneededfor
yourinstallationifusingthe3inchkit.
10. Measuredistancefromoortoairventopeninginap-
plianceandmarklocationonwall.
11. Usesawtocutopeninginwall.
• 2 inch kit:Cuta2-1/2to3inchopeningoninside
wallanda3to3-1/2inchopeningonoutsideof
house.
3 inch kit:Cuta3-1/2to4inchopeningoninside
wallanda4to4-1/2inchopeningonoutsideof
house.
12. UsewiretieorhoseclampdependingontheOutside
AirKittosecureexpipetocollarassembly.
13. Slidetrimringoverexpipeandrunpipethroughwall.
14. Attachexpipetooutsideterminationcapwithsecond
wiretieorhoseclamp.
15. Secureterminationcaptooutsidesurface.
16. Securetrimringtointeriorwall.
WARNING
Maintainminimumclearancestocombustibles
Fire Risk.
FollowFlueManufacturer’sInstructionsfor
ProperInstallation
