Quadra-Fire SANTA FE - F. Baffle & Brick Replacement

Page20
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
F. Bafe & Brick Replacement
1. Placerightbrickinbehindtherightbracketandthen
slidetotheleftsothetabsarebehindthecenterbrick.
Figure 20.1.
2. Thebrickwillbeushagainsttheback wall and the
braket’snotcheswillbeexposed.Figure 20.2.
3. Pulltheright edgeofthebrickforwardand slidethe
brick into the notches both top and bottom of right
bracket.Figure 20.3.
4. Repeatforleftbrick.
5. Insertbafeintotopfrontofreboxandthenraiseup
thebottomendandinsertbafetabintonotchonthe
rightbrackettolockintoplace.Figure 20.5. Placethe
leftsidehookofthebottombafeoverthetopofbrick
forstability.
6. The bafe does not completely cover the top of the
rebox.ThereisanopeningasshowninFigure 20.6.
Tabs
Do not remove rope
from center brick
Brick is flush against back wall
Brick in
front of
clip and
Notches
exposed
Lift Brick, pull forward at an angle
and drop down into notches
Right Brick Installed
Insert Baffle Tab into Slot
Opening at left side of Baffle
Figure 20.1
Figure 20.2
Figure 20.3
Figure 20.4
Figure 20.5
Figure 20.6
