Quadra-Fire SANTA FE - Section 5: Getting Started; A. Design, Installation & Location Considerations; B. Draft

Page22
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
5
Getting Started
Installer’s Guide
A . Design, Installation & Location Considerations
WARNING! Risk of Fire Damagedpartscouldimpairsafe
operation.DoNOTinstalldamaged,incompleteorsubstitute
components.
NOTICE: Checkbuildingcodespriortoinstallation.
• Installation MUST comply with all local building codes
andregulationsincludingthosereferringtonationaland
Europeanstandards.
• Consult insurance carrier, local building inspector, re
ofcialsorauthoritieshavingjurisdictionoverrestrictions,
installationinspectionandpermits.
Itisagoodideatoplanyourinstallationonpaper,usingexact
measurements for clearances and oor protection, before
actuallybeginningtheinstallation.Locationoftheappliance
andchimneywillaffectperformance.
Considerationmustbegivento:
• Safety,convenience,trafcow
• Placementofthechimneyandchimneyconnectorandto
minimizetheuseofchimneyoffsets.
• Placetheappliancewheretherewillbeaclearpassage
foraListedchimneythroughtheceilingandroof(verti-
cal)orthroughexteriorwall(horizontal).
• Installingtherequiredoutsideairkitwillaffecttheloca-
tionoftheventtermination.
Sincepelletexhaustcancontainash,sootor sparks, you
mustconsiderthelocationof:
• Windows
• AirIntakes
• AirConditioner
• Overhang,softs,porchroofs,adjacentwalls
• Landscaping,vegetation
• Horizontalorverticalventtermination
Whenlocatingventandventingtermination,theideallo-
cationistoventaboverooflinewhenpossible.Thismini-
mizestheaffectsofwindloading.
Notice:ThismanualisbasedonNorthAmericaninstallationrequirementsandsomeaspectsmaynotbedirectlyapplicable
toNewZealandinstallations.PleasecontactSwitch(0800765431)formoreinformation.
Draftisthepressuredifferenceneededtoexhaust
appliancessuccessfully.Whenanapplianceisdrafting
successfully,allcombustionby-productsareexitingthe
homethroughtheue.
Considerationsforsuccessfuldraftinclude:
• Preventingnegativepressure
• Locationofapplianceandchimney
Tomeasurethedraftornegativepressureonyour
applianceuseamagnahelicoradigitalpressuregauge
capableofreading0-.25inchesofwatercolumn(W.C.).
Theapplianceshouldberunningonhighforatleast15
minutesforthetest.
Withthestoverunningonhighyoushouldhaveanegative
pressureequaltothenumbergiveninthechartbelow.This
canbeadjustedupordownbyalteringthecombustionfan
speedadjustmentonthecontrolbox(see”Commissioning”
onpage31).Ifafteradjustingthefanspeedyouhavea
lowerreadingthanyoundonthechart,yourstovedoes
nothaveadequatedrafttoburnthefuelproperly.
B . Draft
MODEL
Minimum Vacuum
Requirements
SANTAFE-NZ-MBK 0.085inchesW.C.
Correctlowdraftorlowvacuumproblemsbydoingoneof
thefollowing:
• Thoroughlyinspectandifnecessary,cleantheexhaust
path and ue. See “Cleaning the Exhaust Path” on
page3.Inspectforwornorbrokengaskets.Repairany
gasketssuspectedofleaking.
• Referto“Design,Installation&LocationConsiderations”
on page 22 for recommendations on locating
your appliance and chimney and for causes of and
minimizingnegativepressure
Notice: Hearth & Home Technologies assumes no
responsibilityfortheimproperperformanceoftheuesystem
causedby:
• Inadequatedraftduetoenvironmentalconditions
• Downdrafts
•
Tightsealingconstructionofthestructure
• Mechanicalexhaustingdevices
