Quadra-Fire SANTA FE - B. Clearances to Combustibles

Page26
December 1, 2011
Santa Fe NZ Pellet Stove
R
7068-114B
Straight Back Against Wall
Millimeters
A
BackWalltoAppliance 50
B
SideWalltoAppliance 160
Corner Installation
Millimeters
C
WallstoAppliance 50
Vertical Installation
Millimeters
D
BackWalltoFluePipe 76
E
SideWalltoCastTop 152
F
BackWalltoAppliance 178
Installations with:
76mm to 76mm Top Vent Adapter and
76mm to 152mm Offset Adapter
Corner Installation
Millimeters
G
WallstoAppliance 50
H
SideWalltoFluePipe 76
Alcove Installation
Millimeters
MinimumAlcoveHeight 1092
MinimumAlcoveSideWall 152
MinimumAlcoveWidth 965
MaximumAlcoveDepth 914
Dimension to Corner
Millimeters
I
FlueCenterLine(Santa
Fe/Castile)
217/264
J
BackofTopVentAdapter 232
B. Clearances to Combustibles
FireRisk.
Complywithallminimumclearancesto
combustiblesasspecied.
WARNING
Failuretocomplymaycausehousere.
NOTE:
• IllustrationsreecttypicalinstallationsandareFOR
DESIGNPURPOSESONLY.
•Illustrations/diagramsarenotdrawntoscale.
• Actualinstallationmayvaryduetoindividualdesign
preference.
J
I
C
L
C
C
D
E
F
G
G
H
A
B
