iLevel®
engaged
Figure 3. Q6 Edge 2.0 with iLevel® Feature and Controller Indicators
iLevel® Boot (1 of 2 shown)
Q-Logic 2 Controller NE+ Controller
iLevel® not
engaged
iLevel® engaged
iLevel® not engaged
Single Switch
