To change the armrest width:
1. Locate the two armrest knobs on each side of the armrest receiver
bracket. See fi gure 13.
2. Loosen the knobs.
3. Slide the armrests in or out to the desired width.
4. Tighten the knobs.
To change the controller position:
1. Turn off the power to the controller.
2. Unplug the controller connector(s) from the power base.
3. Remove any wire ties securing the controller harness to the armrest.
4. Flip up the armrest so it is perpendicular to the fl oor.
5. Loosen the setscrew on the controller bracket.
6. Slide the controller out of the armrest.
7. Loosen the setscrew in the other armrest.
8. Place the controller in the other armrest.
Controller Position
You can move the controller in toward or out away from the armrest, or
change the position of the controller for either left-hand or right-hand use.
WARNING! Do not place the controller harness so that it can be pinched
in the seat frame or the power base frame.
To extend the controller:
1. Flip up the armrest so it is perpendicular to the fl oor.
2. Loosen the setscrew on the controller bracket. See fi gure 13.
3. Slide the controller into or out of the armrest to the desired position.
4. Tighten the setscrew to secure the controller.
Armrest Height Adjustment
To change the armrest height:
1. Loosen the two setscrews located on the armrest receiver. See fi g-
ure 13.
2. Raise or lower the armrest to the desired height.
3. Tighten the setscrews to secure the armrest.
Armrest Angle Adjustment
To change the armrest angle:
1. Lift the armrest straight up so that it is perpendicular to the fl oor. See
fi gure 13.
2. Loosen the jam nut.
3. Turn the adjusting screw to raise or lower the front of the armrest.
4. Tighten the jam nut to lock the adjusting screw into place.
