Quantum edge 2.0 - Transit System Securement Brackets; Controller Harness Routing on a TRU-Balance 3; Power Elevating Seat Actuator; Controller Harness Routing on a Contour Seat


1
Figure 7. Controller Harness
Routing on a TRU-Balance® 3
Figure 9. Power Elevating Seat
Actuator
Figure 8. Controller Harness
Routing on a Contour Seat
Figure 10. Transit System
Securement Brackets
Identifi cation Key
Identifi cation Key
Identifi cation Key
1. Seat Plate Interface Bracket
2. Actuator
1. Wire Ties
2. To Power Base
1. Securement Brackets (2 of 4
Shown)
1
2
1
1
2
