Quantum edge 2.0 User Manual


3
1
4
2
Figure 5. Q6 Edge 2.0 Assembly View
Figure 6. Universal Mounting System and Contour Seat
Identifi cation Key
Identifi cation Key
1. Armrest Angle Adjustment
2. Controller Position
3. Foot Platform Angle Adjustment
4. Foot Platform Height/Depth
Adjustment
1. Rear Extrusion
2. Seat Latch Safety
3. Front Extrusion
4. Trapeze Bars
1
2
4
3

Quantum edge 2.0 Specifications

General

Turning Radius	24 inches
Weight Capacity	300 lbs
Per-Charge Range	15 miles
Width	25 inches
Seat Depth	16 inches
