I
NSTALLATION
Options
Ball Return Installation Manual
612
-
860
-
010
5
Rev. Date
10/07
O
PTIONS
B
ALL
L
IFT
NSTALLATION
The standard foundation for the Ball Lift consists of two 2 x 6 x 18
inch boards over a
concrete subfloor. While shims are provided to level and raise the Ball Lift to the
required height, you may need to plane the boards and/or us
e additional materials to
achieve the 14
7/16
inch (367 mm) required distance from the
bottom
surface of the
Ball Lift base plate to the
top
surface of the approach.
Depending on the length of your approach, you may or may not have the ball rack
overhang
ing the end of the approach. To determine the overhang at your center,
perform the computation below using the numbers from your center.
IMPORTANT!
The position of the ball lift on the approach in the following calculation is based on a
standard
Qubic
a
AMF underlane track installation that results in the end of the track being
125
-
7/16 inches from the lane side of the foul line. If possible, check this distance, and if
different, offset the installation (including the cutout) as needed. Minor differe
nces (no
more than ± 1 inch) do
NOT
require any offset. If an installation other than the standard
installation is desired, the underlane track can be lengthened or shortened as needed.
BALL RACK OVERHANG CALCULATION
11
Ball
Rack
15
Ball
Rack
(See Fi
gure 1)
(in inches)
1. Distance from Lane Side of Foul Line to
End of Underlane Track
2. Overall length of ball return
(including 11
-
Ball Rack and Hood)
3.
Subtotal A
4.
Distance from
End of Track
to back
of Hood (overlap of the two items above
)
5.
Subtotal B
6.
Length of Approach (includes Foul Line, your approach may be different)
7.
OVERHANG
F
igure 1, Standard Layout
125.4375
103.
5
228.9375
21.285
207.6525
192.00
1
5
.
6525
125.4375
118
243.4375
21.285
222.1525
192.00
30
.
1525
