QubicaAMF Options Ball Return User Manual

I
NSTALLATION
Options
Ball Return Installation Manual
–
612
-
860
-
010
11
Rev. Date
10/07
I
NSTALLING THE
H
OOD
A
SSEMBLY
The Options Hood Assembly (252
-
002
-
132) is a made up of a base, a hood, a mounting
bracket, and an access panel, as shown in Figure
7
.
Figure
7
,
Options Hood Assembly
NOTE:
The components come assembled and must be separated for installation.
Before separating the components, mark the foul
-
line end of the base. DO NOT
remove the mounting bracket from the access panel.
F
igure
8
,
Options Base Installation
Hood
Base
Access
Panel
Mounting
Bracket
