P
ARTS
Options
Ball Return Installation Manual
–
612
-
860
-
010
Rev. Date
10/07
33
250
-
001
-
008
Clutch Housing Assembly
Part No.
Description
Qty
1
919
-
010
-
910
Retaining ring
2
2
941
-
092
-
320
1ā€ Wrought washer
1
3
070
-
007
-
291
Roller clutch
1
4
250
-
001
-
053
Clutch housing
1
5
250
-
001
-
234
Clutch sleeve
1
6
700
-
112
-
830
RTV Si
licone gasket (not shown)
A/R
