QubicaAMF Options Ball Return User Manual

I
NSTALLATION
Options
Ball Return Installation Manual
–
612
-
860
-
010
17
Rev. Date
10/07
Connecting the Wiring
WARNING
Before wiring the Options Ball Return, all power to the unit must be switched
off at the main breaker box or
serious injury could result.
CAUTION
To avoid equipment malfunction or damage, the power supply must be rated
for the appropriate voltage and current.
1.
Verify that the power to the unit and the associated pinspotters is turned
OFF
at the
main circuit brea
ker.
2.
Verify that the circuit voltage and current ratings correspond to those of the Ball Lift.
All
Ball Lift assemblies
are shipped configured for 230
-
volt operation and, as
necessary, must be reconfigured for 115
-
volt operation as described in this sect
ion.
(Reconfiguring the
motor
for 115
-
volt operation is discussed on Page 5.)
3.
Attach the flexible conduit of the power supply cable (234
-
001
-
330), which is
supplied with the Ball Lift, to the applicable distribution box. Connect the wires in
accordance wi
th local electrical codes. For electrical systems containing a neutral
wire, such as 115
-
volt systems in the United States, connect the green and yellow
wire to ground, the blue wire to neutral, and the brown wire to line.
4.
Remove the cover from the Ball L
ift control box, and then remove a lock nut from the
center and left grounding (earthing) lugs in the control box.
5.
Attach the power supply cable’s flexible conduit to the control box at the
“AC IN”
location shown in Figure 1
5
.
6.
Attach the ring terminal on
the green and yellow ground wire of the power supply
cable to the leftmost grounding (earthing) lug inside the control box using one of the
lock nuts that was removed in Step 4.
7.
Cut off the two spade terminals from the brown and blue power supply wires, an
d
strip approximately 3/8
-
inch of insulation from the ends of these wires.
8.
Connect the
blue wire (neutral) to terminal #6 on junction block
J3
and the brown wire
(line) to terminal #1 on
J3
(see Figure 1
5
).
9.
Strip approximately 3/8
-
inch of insulation fro
m the ends of the brown and blue
blower wires (the blower wires exit the end of a ball rack’s rail assembly). Route this
cable into the control box (see Figure 1
5
). Tighten the cable clamp to secure the
cable to the box.
!
!
