GL100 User manual
4.4. An example to configure GL100
The manager tool is developed based on the @Track Air Interface Protocol. Please refer to “GL100
@Track Air Interface Protocol” for detail.
Following is a general procedure to configure GL100 with manager tool.
4.4.1. Set the parameters of main backend server
Step_7
Step_6
Step_3
Step_2
Step_5
Step_4
Step_1
Step_1: Select “Enable This Function”, after that the parameters of GTSRI can be changed and
the "Send" button is enabled.
Step_2: When “Enable This Function” is selected, the command message which shall be sent to
GL100 will be generated based on input and displayed here. Please note this command
message can also be sent to GL100 through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL100 and edit based on them.
Step_4: Set Report Mode. Please refer to “GL100 @Track Air Interface Protocol” for the meaning
of each choice.
Step_5: Set GPRS parameters. Please contact your SIM card provider to get the correct APN
information.
Step_6: Set the parameters of main backend server.
In the “IP Address” text box, input the internet IP address and port number of main
backend server. The valid value of port number is 0-65535.
TRACGL100UM002 - 14 -
