GL100 User manual
In the “Main SMS Gateway” text box, input the phone number of main SMS gateway
which is used to receive the message from GL100 by SMS. The international format like
“+8615201772961” and short code like “10086” are both supported.
Step_7: Click the “Send” button; download the parameters of GTSRI to GL100.
4.4.2. Set the parameters of secondary backend server
Setp_5
Step_3
Step_4
Step_1
Step_6
Ste
2
Step_1: Select “Enable This Function”, after that the parameters of GTBEI can be changed and
the "Send" button is enabled.
Step_2: When “Enable This Function” is selected, the command message which shall be sent to
GL100 will be generated based on input and displayed here. Please note this command
message can also be sent to GL100 through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL100 and edit based on them.
Step_4: Set the parameters of the secondary backend server.
In the “IP Address” text box, input the internet IP address and port number of the
secondary backend server. The valid value of port number is 0-65535.
Step_5: Location By Call. Configure the “Location By Call” function. Please refer to “GL100
@Track Air Interface Protocol” for detail.
Step_6: Click the “Send” button; download the parameters of GTBEI to GL100.
TRACGL100UM002 - 15 -
