Queclink GL300 - Set the Parameters of Non Movement Detection

GL300 Manage Tool User Guide
TRACGL300MT001 - 26 -
3.2.8 Set the parameters of Non Movement Detection
Step_1: Select “Non Movement Detection”, after that the parameters of GTNMD show in
Command Operation Space.
Step_2: The command message which shall be sent to GL300 will be generated based on input
and displayed here. Please note this command message can also be sent to GL300
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL300 and edit based on them.
Step_4: Set the Non Movement Detection parameters. Please refer to “GL300 @Track Air
Interface Protocol” for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTNMD to GL300.
Step_1
Step_2
Step_4
Step_3
Step_5
