Queclink GL300 User Manual

GL300 @Tracker Air Interface Protocol
3.2. Command and Acknowledgement
3.2.1. Quick Start Setting
The command AT+GTQSS is used to set the GPRS parameter and backend server information in
one command if all these settings are within 160 bytes, otherwise use AT+GTBSI and
AT+GTSRI in two steps.
 AT+GTQSS=
Example:
AT+GTQSS=gl300,cmnet,,,4,,,116.226.44.17,9001,116.226.44.16,9002,+8613812341234,0,1,
,,0001$
Parameter Length (byte) Range/Format Default
Password 4 – 6 ‘0’ – ‘9’, ‘a’ – ‘z’, ‘A’ – ‘Z’ gl300
APN <=40
APN user name <=30
APN password <=30
Report mode 1 0 – 6 0
Reserved 0
Buffer enable 1 0|1|2 1
Main server IP/domain
name
<=60
Main server port <=5 0 – 65535 0
Backup server IP <=15 0.0.0.0
Backup server port <=5 0 – 65535 0
SMS gateway <=20
Heartbeat interval <=3 0|5 – 360min 0
SACK enable 1 0|1 0
Reserved 0
Reserved 0
Serial number 4 0000 – FFFF
Tail character 1 $ $
 <Password>: The valid character of password is ‘0’-9’, ‘a’-‘z’, ‘A’-‘Z’. The default value is
“gl300”.
 <APN>: Access point name (APN).
 <APN user name>: the GPRS APN user name. If the parameter field is empty, the parameter
will be cleared.
 <APN password>: the GPRS APN password. If the parameter field is empty, the parameter
will be cleared.
 <Report mode>: Supports report modes as following:
 0: Stop reporting.
 1: TCP short-connect preferred mode. The connection is based on TCP protocol. The
TRACGL300AN001 - 12 -
Queclink
Confidential
