Quectel EG91 Series

LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 73 / 106
WCDMA B5 HSDPA CH4407 @23.05dBm 553 mA
WCDMA B5 HSUPA CH4407 @ 22.91dBm 556 mA
LTE data
transfer
LTE-FDD B2 CH1100 @23.26dBm 724 mA
LTE-FDD B4 CH2175 @23.52dBm 693 mA
LTE-FDD B5 CH2525 @23.51dBm 613 mA
LTE-FDD B12 CH5060 @23.39dBm 634 mA
LTE-FDD B13 CH5230 @23.3dBm 672 mA
LTE-FDD B25 CH8590@ 23.64dBm 739 mA
LTE-FDD B26 CH8765@ 23.34dBm 647 mA
WCDMA
voice call
WCDMA B2 CH9938 @23.39dBm 571 mA
WCDMA B4 CH1738 @23.27dBm 593 mA
WCDMA B5 CH4357 @ 23.35dBm 554 mA
Table 35: EG91-VX Current Consumption
Parameter Description Conditions Typ. Unit
I
VBAT
OFF state Power down 9 μA
Sleep state
AT+CFUN=0 (USB disconnected)
TBD mA
LTE-FDD PF=64 (USB disconnected) TBD mA
LTE-FDD PF=64 (USB suspended) TBD mA
LTE-FDD PF=256 (USB disconnected) TBD mA
Idle state
LTE-FDD PF=64 (USB disconnected) 16.5 mA
LTE-FDD PF=64 (USB connected) 30.8 mA
LTE data
transfer
LTE-FDD B4 CH2175 @23.36dBm 715 mA
LTE-FDD B13 CH5230 @23.38dBm 642 mA
