Quectel EG91 Series

LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 83 / 106
LTE-FDD B3 (10MHz) -98.3dBm -98.5dBm -101.5dBm -93.3dBm
LTE-FDD B7 (10MHz) -96.3dBm -98.4dBm -101.3dBm -94.3dBm
LTE-FDD B8 (10MHz) -97.1dBm -99.1dBm -101.2dBm -93.3dBm
LTE-FDD B20 (10MHz) -97dBm -99dBm -101.3dBm -93.3dBm
LTE-FDD B28A (10MHz) -98.3dBm -99dBm -101.4dBm -94.8dBm
Table 43: EG91-NA Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
WCDMA B2 -110dBm -110dBm -112.5dBm -104.7dBm
WCDMA B4 -110dBm -110dBm -112.5dBm -106.7dBm
WCDMA B5 -111dBm -111dBm -113dBm -104.7dBm
LTE-FDD B2 (10MHz) -98dBm -99dBm -102.2dBm -94.3dBm
LTE-FDD B4 (10MHz) -97.8dBm -99.5dBm -102.2dBm -96.3dBm
LTE-FDD B5 (10MHz) -99.6dBm -100.3dBm -103dBm -94.3dBm
LTE-FDD B12 (10MHz) -99.5dBm -100dBm -102.5dBm -93.3dBm
LTE-FDD B13 (10MHz) -99.2dBm -100dBm -102.5dBm -93.3dBm
Table 44: EG91-NS Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
WCDMA B2 -110dBm -110dBm -112.5dBm -104.7dBm
WCDMA B4 -110dBm -110dBm -112.5dBm -106.7dBm
WCDMA B5 -111dBm -111dBm -113dBm -104.7dBm
LTE-FDD B2 (10MHz) -98dBm -99dBm -102.2dBm -94.3dBm
