LTE Standard Module Series
EG91 Series Hardware Design
EG91_Series_Hardware_Design 84 / 106
LTE-FDD B4 (10MHz) -97.8dBm -99.5dBm -102.2dBm -96.3dBm
LTE-FDD B5 (10MHz) -99.4dBm -100dBm -102.7dBm -94.3dBm
LTE-FDD B12 (10MHz) -99.5dBm -100dBm -102.5dBm -93.3dBm
LTE-FDD B13 (10MHz) -99.2dBm -100dBm -102.5dBm -93.3dBm
LTE-FDD B25 (10MHz) -97.6dBm -99dBm -102.2dBm -92.8dBm
LTE-FDD B26 (10MHz) -99.1dBm -99.9dBm -102.7dBm -93.8dBm
Table 45: EG91-VX Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
LTE-FDD B4 (10MHz) -98.2dBm -99.2dBm -102.2dBm -96.3dBm
LTE-FDD B13 (10MHz) -99.2dBm -100dBm -102.5dBm -93.3dBm
Table 46: EG91-EX Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
EGSM900 -109.8dBm NA NA -102dBm
DCS1800 -109.8 dBm NA NA -102dbm
WCDMA B1 -110dBm -111dBm -112.5dBm -106.7dBm
WCDMA B8 -110dBm -111dBm -112.5dBm -103.7dBm
LTE-FDD B1 (10MHz) -98.7dBm -98.8dBm -102.4dBm -96.3dBm
LTE-FDD B3 (10MHz) -98.3dBm -99.5dBm -102.5dBm -93.3dBm
LTE-FDD B7 (10MHz) -97.5dBm -98.4dBm -100.3dBm -94.3dBm
LTE-FDD B8 (10MHz) -98.7dBm -99.6dBm -102.2dBm -93.3dBm
LTE-FDD B20 (10MHz) -97dBm -97.5dBm -102.2dBm -93.3dBm
