LTE-FDD B28 (10MHz) -98.2dBm -99.5dBm -102dBm -94.8dBm
Table 47: EG91-NAX Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
WCDMA B2 -110dBm -110dBm -112.5dBm -104.7dBm
WCDMA B4 -110dBm -110dBm -112.5dBm -106.7dBm
WCDMA B5 -111dBm -111dBm -113dBm -104.7dBm
LTE-FDD B2 (10MHz) -98dBm -99dBm -102.2dBm -94.3dBm
LTE-FDD B4 (10MHz) -97.8dBm -99.5dBm -102.2dBm -96.3dBm
LTE-FDD B5 (10MHz) -99.4dBm -100dBm -102.7dBm -94.3dBm
LTE-FDD B12 (10MHz) -99.5dBm -100dBm -102.5dBm -93.3dBm
LTE-FDD B13 (10MHz) -99.2dBm -100dBm -102.5dBm -93.3dBm
LTE-FDD B25 (10MHz) -97.6dBm -99dBm -102.2dBm -92.8dBm
LTE-FDD B26 (10MHz) -99.1dBm -99.9dBm -102.7dBm -93.8dBm
Table 48: EG91-NAXD Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
WCDMA B2 -110dBm -110dBm -112.5dBm -104.7dBm
WCDMA B4 -110dBm -110dBm -112.5dBm -106.7dBm
WCDMA B5 -111dBm -111dBm -113dBm -104.7dBm
LTE-FDD B2 (10MHz) -98dBm -99dBm -102.2dBm -94.3dBm
LTE-FDD B4 (10MHz) -97.8dBm -99.5dBm -102.2dBm -96.3dBm
LTE-FDD B5 (10MHz) -99.4dBm -100dBm -102.7dBm -94.3dBm
