M10 Hardware Design
z Class 1 (1W) at DCS 1800 and PCS 1900
GPRS connectivity
z GPRS multi-slot class 12 （default）
z GPRS multi-slot class 10 (option)
z GPRS multi-slot class 8 (option)
z GPRS mobile station class B
Temperature range
z Normal operation: -35°C ~ +80°C
z Restricted operation: -45°C ~ -35°C and +80°C ~ +85°C
○
1
z Storage temperature: -45°C ~ +90°C
DATA GPRS:
CSD:
z GPRS data downlink transfer: max. 85.6 kbps
z GPRS data uplink transfer: max. 85.6 kbps
z Coding scheme: CS-1, CS-2, CS-3 and CS-4
z Supports the protocols PAP (Password Authentication Protocol)
usually used for PPP connections.
z Integrates the TCP/IP protocol.
z Support Packet Switched Broadcast Control Channel (PBCCH)
z CSD transmission rates: 2.4, 4.8, 9.6, 14.4 kbps,
non-transparent
z Unstructured Supplementary Services Data (USSD) support
SMS z MT, MO, CB, Text and PDU mode
z SMS storage: SIM card
FAX Group 3 Class 1
SIM interface Support SIM card: 1.8V, 3V
Antenna interface Connected via 50 Ohm antenna pad
Audio features Speech codec modes:
z Half Rate (ETS 06.20)
z Full Rate (ETS 06.10)
z Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80)
z Adaptive multi rate (AMR)
z Echo Cancellation
z Echo Suppression
z Noise Reduction
Serial port and Debug port z Serial Port: Seven lines on Serial Port Interface
z Serial Port can be used for CSD FAX, GPRS service and send
AT command of controlling module.
z Serial Port can use multiplexing function.
z Autobauding supports baud rate from 4800 bps to 115200bps.
z Debug Port: Two lines on Serial Port Interface /TXD and /RXD
z Debug Port only used for debugging
Phonebook management Support phonebook types: SM, FD, LD, RC, ON, MC.
SIM Application Toolkit Support SAT class 3, GSM 11.14 Release 99
Real time clock Implemented
Alarm function Programmable via AT command
Physical characteristics Size:
M10_HD_V1.00 - 14 -
