Table 26: Pin definition of the LIGHT_MOS
Name
Pin
Function
LIGHT_MOS
27
Open Drain
Output Port
Note: This function is not supported in the defau
lt firmwar
e. There must be special firmwar
e if
you re
quire. P
lease contact
Quectel for
mor
e deta
ils .
MODULE
300R
VBAT
LIGHT_MOS
Figure 37
: Reference circuit of the LIGHT_MOS
M10_HD_V1.00
-
5
4
-
Quectel
54
56
