Quectel M10 Hardware Description

M10 Hardware Design
Condition Current Consumption
Voice Call
GSM850 @power level #5 <300mA,Typical 290mA
@power level #10,Typical 150mA
@power level #19,Typical 100mA
EGSM 900 @power level #5 <300mA,Typical 270mA
@power level #10,Typical 140mA
@power level #19,Typical 100mA
DCS 1800 @power level #0 <250mA,Typical 240mA
@power level #10,Typical 150mA
@power level #15,Typical 100mA
PCS 1900 @power level #0 <250mA,Typical 250mA
@power level #10,Typical 150mA
@power level #15,Typical 100mA
GPRS Data
DATA mode, GPRS ( 1 Rx,1 Tx ) CLASS 12
GSM850 @power level #5 <350mA,Typical 280mA
@power level #10,Typical 145mA
@power level #19,Typical 90mA
EGSM 900 @power level #5 <350mA,Typical 260mA
@power level #10,Typical 135mA
@power level #19,Typical 90mA
DCS 1800 @power level #0 <300mA,Typical 200mA
@power level #10,Typical 120mA
@power level #15,Typical 90mA
PCS 1900 @power level #0 <300mA,Typical 230mA
@power level #10,Typical 130mA
@power level #15,Typical 90mA
DATA mode, GPRS ( 3 Rx, 2 Tx ) CLASS 12
GSM850 @power level #5 <550mA,Typical 530mA
@power level #10,Typical 265mA
@power level #19,Typical 145mA
EGSM 900 @power level #5 <550mA,Typical 485mA
@power level #10,Typical 250mA
@power level #19,Typical 145mA
DCS 1800 @power level #0 <450mA,Typical 370mA
@power level #10,Typical 165mA
@power level #15,Typical 135mA
PCS 1900 @power level #0 <450mA,Typical 390mA
@power level #10,Typical 220mA
@power level #15,Typical 128mA
DATA mode, GPRS ( 4 Rx,1 Tx ) CLASS 12
GSM850 @power level #5 <350mA,Typical 320mA
M10_HD_V1.00 - 61 -
