PCM_IN 263 DI PCM data input
V
IL
min = -0.3 V
V
IL
max = 0.63 V
V
IH
min = 1.17 V
V
IH
max = 2.1 V
PCM_OUT 261 DO PCM data output
V
OL
max = 0.45 V
V
OH
min = 1.35 V
PCIe Interface
Pin Name Pin No. I/O Description
DC
Characteristics
Comment
PCIE_REFCLK
_P
40 AO
PCIe reference
clock (+)
Require differential
impedance of 95 Ω.
If unused, keep
them open.
PCIE_REFCLK
_M
38 AO
PCIe reference
clock (-)
PCIE_TX_M 44 AO PCIe transmit (-)
PCIE_TX_P 46 AO PCIe transmit (+)
PCIE_RX_M 32 AI PCIe receive (-)
PCIE_RX_P 34 AI PCIe receive (+)
PCIE_CLKREQ 36 IO PCIe clock request
V
OL
max = 0.45 V
V
OH
min = 1.35 V
V
IL
min = -0.3 V
V
IL
max = 0.63 V
V
IH
min = 1.17 V
V
IH
max = 2.1 V
1.8 V power domain
If unused, keep
them open.
PCIE_RST 39 DO PCIe reset
V
OL
max = 0.45 V
V
OH
min = 1.35 V
PCIE_WAKE 30 DI PCIe wakeup
V
IL
min = -0.3 V
V
IL
max = 0.63 V
V
IH
min = 1.17 V
V
IH
max = 2.1 V
RGMII Interface
Pin Name Pin No. I/O Description
DC
Characteristics
Comment
RGMII_MD_IO 10 IO
RGMII MDIO
management data
Power domain
determined by
RGMII_PWR_IN
If unused, keep
them open.
RGMII_MD_
CLK
11 DO
RGMII MDC
management clock
RGMII_RX_0 13 DI
RGMII receive data
bit 0
