Quectel QuecOpen AG525R-GL

Automotive Module Series
AG525R-GL QuecOpen
Hardware Design
AG525R-GL_QuecOpen_Hardware_Design 84 / 104
5.5. RF Output Power
The following table shows the RF output power of the module.
Table 35: RF Output Power
EGSM900, PCL = 19 @ 5.0dBm 125.1 mA
DCS1800, PCL = 0 @ 30 dBm 248.9 mA
DCS1800, PCL = 7 @ 16.0dBm 139.2 mA
DCS1800, PCL = 15 @ 0dBm 132 mA
PCS1900, PCL = 0 @ 30 dBm 255.6 mA
PCS1900, PCL = 7 @ 16.0dBm 138.8 mA
PCS1900, PCL = 15 @ 0dBm 129.8 mA
WCDMA voice call
WCDMA B1 @ 22.5 dBm 620.63 mA
WCDMA B2 @ 22.5 dBm 666.99 mA
WCDMA B3 @ 22.5 dBm 623 mA
WCDMA B4 @ 22.5 dBm 659.48 mA
WCDMA B5 @ 22.5 dBm 612.57 mA
WCDMA B8 @ 23.0dBm 615.13 mA
WCDMA B9 @ 23.0dBm 671.92 mA
WCDMA B19 @ 23.0dBm 598.64 mA
Frequency Max. Min.
EGSM900 33 dBm ±2 dB 5 dBm ±5 dB
GSM850 33 dBm ±2 dB 5 dBm ±5 dB
DCS1800 30 dBm ±2 dB 0 dBm ±5 dB
PCS1900 30 dBm ±2 dB 0 dBm ±5 dB
