5.4. Current Consumption
Table 34: Module Current Consumption (25 °C, 3.8 V Power Supply)
Description Conditions Typ. Unit
OFF state Power down 0.021 mA
Sleep state
AT+CFUN=0 (USB disconnected)
1.144 mA
GSM850 DRX = 2 (USB disconnected) 3.183 mA
GSM850 DRX = 5 (USB disconnected) 2.128 mA
GSM850 DRX = 5 (USB suspend) TBD mA
GSM850 DRX = 9 (USB disconnected) 1.760 mA
EGSM900 DRX = 2 (USB disconnected) 3.160 mA
EGSM900 DRX = 5 (USB disconnected) 2.181 mA
EGSM900 DRX = 5 (USB suspend) TBD mA
EGSM900 DRX = 9 (USB disconnected) 1.868 mA
DCS DRX = 2 (USB disconnected) 3.191 mA
DCS DRX = 5 (USB disconnected) 2.157 mA
DCS DRX = 5 (USB suspend) TBD mA
DCS DRX = 9 (USB disconnected) 3.175 mA
PCS DRX = 2 (USB disconnected) 3.156 mA
PCS DRX = 5 (USB disconnected) 2.154 mA
PCS DRX = 5 (USB suspend) TBD mA
PCS DRX = 9 (USB disconnected) 3.886 mA
WCDMA PF = 64 (USB disconnected) 3.295 mA
WCDMA PF = 64 (USB suspend) TBD mA
WCDMA PF = 128 (USB disconnected) 2.458 mA
