Page #70 background imageLoading...
Page #70 background image
Automotive Module Series
AG525R-GL QuecOpen
Hardware Design
AG525R-GL_QuecOpen_Hardware_Design 69 / 104
3.19. GPIO Interfaces
The module provides 11 GPIOs.
Table 27: Pin Definition of GPIOs
Pin Name Pin No. I/O Description Comment
GPIO1 100 IO
General-purpose input/output
1.8 V power domain.
If unused, keep them
open.
GPIO2 101 IO
GPIO3 102 IO
GPIO4 104 IO
GPIO5 116 IO
GPIO6 243 IO
GPIO7 246 IO
GPIO8 249 DO
GPIO9 264 IO
GPIO10 267 IO
GPIO11 289 IO
