5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 13 / 85
2 Product Concept
2.1. General Description
RM500Q-GL is a 5G NR/LTE-FDD/LTE-TDD/UMTS/HSPA+ wireless communication module with receive
diversity. It provides data connectivity on 5G NR SA and NSA, LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+,
HSDPA, HSUPA and WCDMA networks. RM500Q-GL is standard M.2 Key-B WWAN module. For more
details, see PCI Express M.2 Specification Revision 3.0, Version 1.2.
RM500Q-GL is an industrial-grade module for industrial and commercial applications only.
RM500Q-GL supports embedded operating systems such as Windows, Linux and Android, and also
provides GNSS and voice functionality to meet specific application demands.
The following table shows the frequency bands and GNSS systems of RM500Q-GL module.
Table 2: Frequency Bands and GNSS Systems of RM500Q-GL Module
