5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 14 / 85
RM500Q-GL can be applied in the following fields:
⚫ Rugged tablet PC and laptop computer
⚫ Remote monitor system
⚫ Smart metering system
⚫ Wireless CPE
⚫ Smart TV
⚫ Outdoor Live devices
⚫ Wireless router and switch
⚫ Other wireless terminal devices
2.2. Key Features
The following table describes key features of RM500Q-GL.
Table 3: Key Features of RM500Q-GL
⚫ PCI Express M.2 Interface
⚫ Supply voltage: 3.135–4.4 V
⚫ Typical supply voltage: 3.7 V
⚫ Compliant with ISO/IEC 7816-3
⚫ Supported (U)SIM card: Class B (3.0 V) and Class C (1.8 V)
⚫ (U)SIM1 and (U)SIM2 interfaces
⚫ Dual SIM Single Standby
⚫ Compliant with USB 3.1 and 2.0 specifications, with maximum transmission
rates up to 10 Gbps on USB 3.1 and 480 Mbps on USB 2.0.
⚫ Used for AT command communication, data transmission, firmware upgrade,
software debugging, GNSS NMEA sentence output and voice over USB.
⚫ Supported USB serial drivers: Windows 7/8/8.1/10, Linux 2.6–5.4, Android
4.x/5.x/6.x/7.x/8.x/9.x/10
⚫ Complaint with PCIe Gen 3
⚫ PCIe × 1, supporting 8 Gbps per lane.
⚫ Used for AT command communication, data transmission, firmware upgrade,
software debugging, GNSS NMEA sentence output
⚫ Used for audio function with external codec
⚫ Supports 16-bit linear data format
⚫ Supports long and short frame synchronization
⚫ Supports master and slave modes, but must be the master in long frame
To Next Page
