1)
SIMO is a smart antenna technology that uses a single antenna at the transmitter side and two
antennas at the receiver side, which improves Rx performance.
5.1.5. Output Power
The following table shows the RF output power of the module.
Table 34: RF Output Power
5G NR-FDD n20 (20 MHz)
(SCS: 15 kHz)
-92.5
-94.5
-95.5
-89.8 dBm
5G NR-FDD n25 (20 MHz)
(SCS: 15 kHz)
-91
-91
-94
-90.5 dBm
5G NR-FDD n28 (20 MHz)
(SCS: 15 kHz)
-97
-98
-99.5
-90.8 dBm
5G NR-TDD n38 (20 MHz)
(SCS: 30 kHz)
-94
-93.5
-97
-90.6 dBm
5G NR-TDD n40 (20 MHz)
(SCS: 30 kHz)
TBD
TBD
TBD
-94.0 dBm
5G NR-TDD n41 (100 MHz)
(SCS: 30 kHz)
-83.5
-83.5
-87
-84.0 dBm
5G NR-FDD n48* (20 MHz)
(SCS: 15 kHz)
TBD
TBD
TBD
--92.9 dBm
5G NR-FDD n66 (20 MHz)
(SCS: 15 kHz)
TBD
TBD
TBD
-93.5 dBm
5G NR-FDD n71 (20 MHz)
(SCS: 15 kHz)
TBD
TBD
TBD
-85.3 dBm
5G NR-TDD n77 (100 MHz)
(SCS: 30 kHz)
-85
-84
-90
-87.8 dBm
5G NR-TDD n78 (100 MHz)
(SCS: 30 kHz)
-84.5
-87
-90
-87.8 dBm
5G NR-TDD n79 (100 MHz)
(SCS: 30 kHz)
-84.5
-87
TBD
-87.8 dBm
Mode
Frequency
Max.
Min.
WCDMA
WCDMA bands
24 dBm +1/-3 dB (Class 3)
< -50 dBm
LTE
LTE bands
23 dBm ±2 dB (Class 3)
< -40 dBm
NOTE
