5.1.2. Pin Mapping
Table 31: RM500Q-GL Cellular Antenna Mapping
1.
1)
NR TRX1 = TX MIMO + PRX MIMO; NR DRX1 = DRX MIMO.
2.
2)
LTE UHB frequency range: 3400–3800 MHz.
5.1.3. Operating Frequency
Table 32: Module Operating Frequency
Antenna
5G NR
WCDMA/LTE
LB
(MHz)
MHB
(MHz)
n77/n78
(MHz)
n79
(MHz)
Refarmed
n41
n77/n78/n79
ANT0
LMHB TRX
TRX1
1)
TRX1
1)
LTE LMHB TRX;
LTE UHB PRX MIMO
2)
;
WCDMA LMHB TRX;
617–960
1452–2690
3300–4200
4400–5000
ANT1
MHB PRX
MIMO
TRX0
DRX0
LTE MHB PRX MIMO;
LTE UHB DRX
2)
;
LAA PRX;
-
1452–2690
3300–4200
4400–5000
ANT2_
GNSSL1
MHB DRX
MIMO
DRX0
DRX1
1)
LTE MHB DRX MIMO;
LTE UHB DRX MIMO
2)
;
LAA DRX;
-
1452–2690
3300–4200
4400–5000
ANT3
LMHB DRX
DRX1
1)
TRX0
LTE LMHB DRX;
LTE UHB TRX
2)
;
WCDMA LMHB DRX;
617–960
1452–2690
3300–4200
4400–5000
Band Name
Transmit (MHz)
Receive (MHz)
LTE-FDD
LTE-TDD
UMTS
5G NR
IMT (2100)
1920–1980
2110–2170
B1
–
B1
n1
PCS (1900)
1850–1910
1930–1990
B2
–
B2
n2
DCS (1800)
1710–1785
1805–1880
B3
–
B3
n3
AWS
1710–1755
2110–2155
B4
–
B4
–
Cell (850)
824–849
869–894
B5
–
B5
n5
JCELL (800)
830–840
875–885
–
–
–
–
IMT-E (2600)
2500–2570
2620–2690
B7
–
–
n7
