Quectel RM500Q-GL User Manual

5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 23 / 85
1.
1)
This pin is pulled LOW by default, and will be internally pulled up to 1.8 V by software configuration
only when (U)SIM hot-plug is enabled by AT+QSIMDET.
2.
2)
If this function is required, please contact Quectel for more details.
3. Keep all NC, reserved and unused pins unconnected.
69
CONFIG_1
DO
Connected to GND
internally
70
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
71
GND
Ground
72
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
73
GND
Ground
74
VCC
PI
Power supply
Vmin = 3.135 V
Vnorm = 3.7 V
Vmax = 4.4 V
75
CONFIG_2
DO
Not connected
internally
