Legend:
a. Coffee brew group
b. Coffee delivery control
c. Filter holder
d. Steam valve
e. Steam wand
f. Hot water valve
g. Hot water wand
h. Boiler gauge
+ Pump gauge
i. Termopid
j. Cup warmer
k. Water tank
l. Drip tray
m. General switch ON/OFF
n. Machine ON green light
o. Coffee heating red light
p. Steam switch
q. Steam ON green light
r. Steam heating red light
s. Tank/service valve
t. Tank/service switch (0=tank;1=service)
u. Direct discharge tank
v. Pump pressure adjustment
w. Water tank lid
x. Led switch (if present)
S
IZE
l x h x p
W
EIGHT
:
V
OLTAGE
:
P
OWER
220V/230V:
P
OWER
115 V:
T
ANK CAPACITY
C
OFFEE TANK CAPACTY
:
S
TEAM TANK CAPACITY
:
W
ORKING TEMPERATURE
:
330
X
405
X
465 mm
28 K
G
200-240 V – 50-60 H
Z
/ 120
V
– 60 H
Z
2350 W
2050 W
3
LITRES
0,75
LITRES
1,40
LITRES
+5°C ÷ +35°C
Commissioning
The 0995 Vetrano dosata 2 Boiler Pid, model can be supplied either with water
coming from the tank or from the water mains. According to the type of supply,
proceed as follows.
Tank
- Position the tank/service tap (s), underneath the machine, on tank.
- Position the tank/service switch (t) on tank.
- Fill the water tank (use drinking water, softened if possible).
