328
Factory parameters preset
With the PRESET operation, the TermoPID control unit can be reconfigured with
the default parameters (factory data).
To perform the PRESET, proceed as follows:
- With the termopid disabled. press
▼.
-
Power the board.
-
When the display shows “prs” release the key.
-
Cut-out the power to the board.
The factory data (default) is the following:
F01 - °C
F02 – 6
P1 – 1,5
I1 – 0,0
D1 – 1,5
B1 – 10
P2 – 1,5
I2 – 0,0
D2 – 1,5
B2 – 6
T1 – 95
T2 – 124
E1 – 15
E2 - 0
Alarms
In the case of a sensor failure, on the display the caption A1 (or A3 for the Vetrano
model) is shown: the adjustment and programming outputs are disabled.
In the case of a sensor short circuit, on the display the caption A2 (or A4 for the
Vetrano model) is shown: the adjustment and programming outputs are disabled.
