Model: Quickie Salsa M
2
Mini
14.0 Specification sheets (EN 12184 & ISO 7176-15)
Sunrise Medical
Thorns Road
Brierley Hill
West Midlands
DY5 2LD
Phone: 0845 605 66 88
www.SunriseMedical.co.uk
Operating temperature: - 25°C to 50°C
Storage temperature: -40°C to 65°C
Moisture resistance: IPx4
No restrictions on humidity and air pressure
ISO 7176-15 Min Max Comments
Overall length (with legrest) - 1120 mm (1,12 m) With Uni type hangers
Overall width powerbase - 520 mm
Overall width seat 530 mm 630 mm Across std armpads
Folded length N.A N.A Not a folding wheelchair
Folded height N.A N.A Not a folding wheelchair
Total mass (w/batteries) 97kg 112kg Basic / With 30º tilt
Mass of the heaviest part 69kg 84kg Removable parts taken off
Static stability downhill 11º - Power tilt – 0º
Recline – 0º
FSH - 470 mm
Seat – 16”/400 mm
Static stability uphill 9º - Power tilt – 30º
Recline – 16º
FSH - 470 mm
Seat – 20”/500 mm
Static stability sideways 10º - Power tilt – 30º
Recline – 16º
FSH - 470 mm
Seat – 20”/500 mm
Energy consumption (Max. range) - 23 km
Dynamic stability uphill 6º 8º Depending on options
Obstacle climbing 50 mm 70 mm No-run / 500 mm (0.5m
run)
Maximum speed forward 3.2km/h (2mph) 6.4 km/h (4mph) Dep. Programming option
Minimum braking distance from max. speed - 1200 mm (1,2 m)
Seat plane angle -5º 30º Depends on option
Effective seat depth 410 mm 510 mm 25 mm increments
Effective seat width 410 mm 510 mm 25 mm increments
Seat surface height at front edge 430 mm 49 mm Depends on option
Backrest angle -5° 30º Depends on option
Backrest height 460 mm 510 mm
Footrest to seat distance 360 mm 510 mm With Uni type hangers
Leg to seat surface angle - 84º With Uni type hangers
Armrest to seat distance 230 mm 310 mm
Front location of armrest structure 370 mm 470 mm
Minimum turning radius - 700 mm With Uni type hangers
Mass of the test dummy - 140kg
EN 12184 Min Max Comments
Maximum height of kerb safely descend - 70mm
Minimum width of corridor - 1140mm With Uni type hangers
Minimum ground clearance 35mm -
Speed control operation force - 1,8 N
Direction control operation force - 1,5 N
Maximum occupant
mass (test dummy
mass): 140 kg
The wheelchair
Quickie Salsa
conforms to the
following standards:
a) requirements and
test methods for
static, impact and
fatigue strengths
(ISO 7176-8)
b) power and
control systems for
electric wheelchairs
requirements and
test methods (ISO
7176-14)
c) climatic test in
accordance with
ISO 7176-9
d) requirements for
resistance to ignition
in accordance with
ISO 7176-16
e) the product is
specified as a Class
B power wheelchair,
but with limited
range.
