Quincy Compressor QOF 20 - Section III - Controller; Control panel

Section III - Controller
14 Quincy Compressor
• General
• Control panel
• Icons used
• Main screen
• Calling up menus
• Shutdown warning
• Shutdown
• Inputs menu
• Outputs menu
• Counters
• Control mode selection
• Service menu
• Setpoint menu
• Event history menu
• General settings menu
• Info menu
• Week timer menu
• Test menu
• User password menu
• Web server
• Programmable settings
General
Control panel
Introduction
Thecontrollerhasfollowingfunctions:
•Controllingthecompressor
•Protectingthecompressor
•Monitoringcomponentssubjecttoservice
•Automaticrestartaftervoltagefailure(madeinactive)
Automatic control of the compressor operation
Thecontrollermaintainsthenetpressurebetweenprogrammablelimitsbyautomatically
startingandstoppingoneormorecompressormodules.Anumberofprogrammable
settings, e.g. the starting and stopping pressures and the maximum allowed motor
