Quincy Compressor QOF 20 - Shutdown

Section III - Controller
Quincy Compressor 31
Shutdown
Description
Thecompressorwillshutdownincaseof:
•Toohighambienttemperature
•Motoroverload
•Outletpressuresensorerror
High ambient temperature
Iftheambienttemperatureisabovethefactorysetshutdowntemperature(45°C-113
°F),thecompressorwillbestoppedandastopiconwillbeshownonthemainscreenof
thecontroller:
Main screen - shutdown by too high ambient temperature
Textonimage
(1) Compressor outlet (pressure)
(2) Stop icon
(3) Shutdown
(4) Menu
Motor overload
Amotoroverloadrelayprotectsthemotorofeachcompressormodule.Themotoris
shutdown if the motor current is too high.
