Section IX - Technical data
Quincy Compressor 91
• Electric cable size and fuses
• Reference conditions and limitations
• Compressor data
Electric cable size and fuses
Notice!
• The voltage on the compressor terminals must not deviate more than 10% of the
nominal voltage. It is however highly recommended to keep the voltage drop over
the supply cables at nominal current below 5% of the nominal voltage (IEC 60204-1).
• If cables are grouped together with other power cables, it may be necessary to use
cables of a larger size than those calculated for the standard operating conditions.
• Use the original cable entry, indicated on the dimension drawings.
To preserve the IP protection degree of the electric cubicle and to protect its
components from dust from the environment, it is mandatory to use a proper cable
gland when connecting the supply cable to the compressor.
• Local regulations remain applicable if they are stricter than the values proposed below..
• Caution:
• Always double-check the fuse size versus the calculated cable size. If required,
reduce fuse size or enlarge cable size.
• Cable length should not exceed the maximum length according to IEC 60204 table
10.
Currents and fuses
Compressor
type
Itot(1)
Max
fuse
(1)
Itot(2)
Max
fuse
(2)
Q21/
Q22/
Q23/
Q24
Q15
QOF20 IEC 50Hz 230V 55A 63A 60A 80A 15.0A
QOF20 IEC 60Hz 380V 32A 40A 37A 50A 8.9A
QOF20 IEC 50Hz 400V 32A 35A 35A 50A 8.7A
QOF20 IEC 50Hz
400V
+N
32A 35A 37A 50A 8.7A
QOF20 UL/cUL 60Hz 200V 60A 70A 68A 80A 16.6A
QOF20 UL/cUL 60Hz 230V 55A 70A 62A 80A 15.0A
QOF20 UL/cUL 60Hz 460V 28A 35A 31A 40A 8.0A
QOF20 UL/cUL 60Hz 575V 21A 30A 24A 35A 5.9A
