Inputs menu
Menu icon, Inputs
Function
•Todisplaytheactualvalueofthemeasureddata(analoginputs)andthestatusofthe
digital inputs (e.g. emergency stop contact, motor overload relay, etc.).
•Toselectthedigitalinputtobeshownonthechartinthemainscreen.
Procedure
Starting from the Main screen,
•MovethecursortotheactionbuttonMenuandpresstheEnterkey.Followingscreen
appears:
Textonimage
(1) Menu
(2) Regulation
•UsingtheScrollkeys,movethecursortotheInputsicon(seeabove,sectionMenu
icon).
•PresstheEnterkey.Ascreensimilartotheonebelowappears:
Textonimage
(1) Inputs
(2) Compressor outlet
