Quincy Compressor QOF 20 - Event History Menu

Section III - Controller
Quincy Compressor 45
Event history menu
Menu icon, Event History
Function
Tocallupthelastshutdownandlastemergencystopdata.
Procedure
Starting from the Main screen,
•UsingtheScrollkeys,movethecursortotheactionbuttonMenuandpresstheEnter
key.Followingscreenappears:
Textonimage
(1) Menu
(2) Regulation
•UsingtheScrollkeys,movethecursortotheEventHistoryicon(seeabove).
•PresstheEnterkey.Thelistoflastshutdownandemergencystopcasesisshown.
Example of Event History screen
•Scrollthroughtheitemstoselectthedesiredshutdownoremergencystopevent.
•PresstheEnterkeytofindthedate,timeandotherdatareflectingthestatusofthe
compressor when that shutdown or emergency stop occurred.
