Section VII - Adjustments and servicing procedures
Quincy Compressor 83
• Air filter
• Air cooler
• Drive motor
• Safety valve
• Belt set exchange and tensioning
• Cleaning the compressor element
• Replacement of the outlet pipe
• Dryer maintenance
Air filter
Procedure
3.7 kW compressor module
5.5 kW compressor module
1. Stop the compressor, close the air outlet valve and switch off the voltage.
2.Removetheltercover(1)andthelterelement.Discarddamagedorclogged
elements. Clean the cover.
3.Fitthenewelementandreinstalltheltercover.
Air cooler
Cleaning
Keepthecoolercleantomaintaincoolingefciency.Ifnecessary,removeanydirtwitha
brebrush.Neveruseawirebrushormetalobjects.
Next,cleanbyairjetinreversedirectionofnormalow.
