Quincy Compressor QOF 20 - Icons used

Section III - Controller
Quincy Compressor 17
Icons used
Status icons
Name Icon Description
Stopped / Running
Whenthecompressorisstopped,theiconstandsstill.
Whenthecompressorisrunning,theiconisrotating.
Compressor status Motor stopped
Motor running
Machine control
mode
Or
Local start / stop
Remote start / stop
Networkcontrol
Automaticrestart
after voltage failure
Automaticrestartaftervoltagefailureisactive
Weektimer Weektimerisactive
