Instruction Reference Manual 57
Description
If the condition f is true then the 16-bit data mn is loaded into PC. If the condition is false then PC increments
normally.
The condition f is one of the following: NZ, Z flag not set; Z, Z flag set; NC, C flag not set; C, C flag set; LZ,
L/V flag is not set; LO, L/V flag is set; P, S flag not set; M, S flag set.
This instruction recognizes labels when used in the Dynamic C assembler.
JP f,mn
Opcode Instruction Clocks Operation
——
C2 nm
CA nm
D2 nm
DA nm
E2 nm
EA nm
F2 nm
FA nm
JP f,mn
JP NZ,mn
JP Z,mn
JP NC,mn
JP C,mn
JP LZ,mn
JP LO,mn
JP P,mn
JP M,mn
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
7 (2,2,2,1)
if {f}PC=mn
if {NZ} PC = mn
if {Z} PC = mn
if {NC} PC = mn
if {C} PC = mn
if {LZ/NV} PC = mn
if {LO/V} PC = mn
if {P} PC = mn
if {M} PC = mn
Flags ALTD I/O
S Z L/V C F R SP S D
- - - -
To Next Page
