RADIOMETER FLEX ABL90 User Manual

8
Syringe samples – how to measure a patient
sample, continued
3. Introducing the sample
Present the following steps on how to introduce the sample.
Then the trainee:
1. Should repeat the steps as a practical exercise.
2. Should be informed that the analyzer will guide with on-screen video, sound and
instructions during the process.
Key words:
LIFT – ALIGN – PUSH – HOLD – REMOVE – CLOSE
LIFT
• Lift the inlet to the "syringe" position until the
green light appears
ALIGN
• Align sampler with inlet gasket
• If available, select mode
PUSH
• Push the sampler onto the inlet, applying
pressure to depress the inlet gasket
HOLD
• Hold the sampler in place while the sample is
automatically aspirated
REMOVE
• Gently remove the sampler from the inlet
when prompted
CLOSE
• Close the inlet
No safe TIPCAP
With
safe TIPCAP
8 of 36EXT-VEND-MAN-0023-1 Owner:Julie Monnox Approved:27 Mar 2019

RADIOMETER FLEX ABL90 Specifications

General

Analyzer Type	Blood Gas Analyzer
Analysis Time	35 seconds
User Interface	Touch screen
Power Supply	100-240 V AC, 50/60 Hz
Parameters Measured	pH, pCO2, pO2
Sample Type	Whole blood
Sample Volume	65 µL
Calibration	Automatic
Connectivity	USB, Ethernet
Operating Temperature	15-30°C
Operating Humidity	20-85% relative humidity, non-condensing
