Advanced menu
45
IDE/SATA configuration
When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE
devices and displays the following items.
USB 2.0 Controller This feature displays the current USB controller used in the motherboard.
Legacy USB Support Select Enabled to use Legacy USB devices. If this item is set to Auto, Legacy USB
support is automatically enabled if a legacy USB device is installed on the
motherboard. The settings are Disabled, Enabled and Auto.
Table 46. IDE/SATA Configuration submenu
BIOS item Usage
SATA#1 Configuration Selecting Compatible sets SATA#1 to legacy compatibility mode, while selecting
Enhanced sets SATA#1 to native SATA mode. The options are Disabled, Compatible
and Enhanced.
Configure SATA#1 as This feature enables you to select the drive type for SATA#1. The options are IDE,
RAID and AHCI. When RAID is selected, the ICH RAID Code Base option appears.
When AHCI is selected, the SATA AHCI option appears.
ICH RAID Code Base
(available when Configure
SATA#1 as RAID is
selected)
Select Intel to enable Intel's SATA RAID firmware to configure Intel's SATA RAID
settings. Select Adaptec to enable Adaptec's SATA RAID firmware to configure
Adaptec's SATA RAID settings. The options are Intel and Adaptec.
SATA#2 Configuration
(available when Configure
SATA#1 as IDE is selected)
Selecting Enhanced sets SATA#2 to native SATA mode. The options are Disabled, and
Enhanced.
IDE Detect Timeout (sec) Use this feature to set the time-out value for the BIOS to detect the ATA and ATAPI
devices installed in the system. The options are 0 (sec), 5, 10, 15, 20, 25, 30, and 35.
Table 45. Advanced Chipset Control submenu (Continued)
BIOS item Usage
