Set LAN configuration
Set this feature to configure the IPMI LAN adapter with a network address.
SET PEF configuration
Table 55. Set LAN Configuration submenu
BIOS item Usage
Channel Number Enter the channel number for the SET LAN Config command. This is initially set to
[01]. Press “+” or “-” to change the channel number.
Channel Number Status This feature returns the channel status for the selected channel number. The status is
“Channel Number is OK” or “Wrong Channel Number.”
IP Address Source Select the source of this machine's IP address. If Static is selected, you must
manually enter the IP address of the machine. If DHCP is selected, the BIOS searches
for a DHCP (Dynamic Host Configuration Protocol) server in the network it is
attached to, and requests the next available IP address. The options are DHCP and
Static. If DHCP is selected, the following items will display:
IP Address – Enter the IP address for this machine. This should be in decimal and
in dotted quad form. The value of each three-digit number separated by dots
should not exceed 255.
Subnet Mask – Subnet masks tell the network which subnet this machine
belongs to. The value of each three-digit number separated by dots should not
exceed 255.
Gateway Address – This is the IP address of the gateway in the network. This is
usually a router.
Mac Address – The BIOS will automatically enter the Mac address of this
machine; however it may be overridden. Mac addresses are 6 two-digit hexadeci-
mal numbers (Base 16, 0 – 9, A, B, C, D, E, F) separated by dots. (for example,
00.30.48.D0.D4.60).
Table 56. SET PEF Configuration submenu
BIOS item Usage
PEF Support Select Enabled to enable the function of Platform Event Filter (PEF). The PEF
interprets BMC events and perform actions based on predetermined settings or
events under IPMI 1.5 specifications (for example, powering the system down or
sending an alert when a triggering event is detected). The default is Disabled.
PEF Action Global Control
(available if PEF Support is
enabled)
These are the different actions based on BMC events. The options are Alert, Power
Down, Reset System, Power Cycle, OEM Action, Diagnostic Interface.
Alert Startup Delay
(available if PEF Support is
enabled)
This feature inserts a delay during startup for PEF alerts. The options are Enabled and
Disabled.
PEF Alert Startup Delay
(available if Alert Startup
Delay is enabled)
This feature enables you to select the delay time setting for PEF Alerts after power-up
from S4, S5 or Reset. The options are No Delay, 30 Sec., 60 Sec., 1.5 Min., and 2.0
Min.
