RadiSys PROCELERANT SB5520DT1-SATA - Page 56

3
BIOS Configuration
56
Table 54. Sensors and SEL data
Number Name Type Data interpretation Event description
00h CPU1 Temp 01: Temperature Temperature = Data Over heat warning
01h CPU2 Temp 02: Voltage Temperature = Data
02h Sys Temp 03: Current Temperature = Data
03h CPU1 Vcore 04: Fan Voltage = Data × 0.008 Threshold warning
(high nonrecoverable,
high critical,
high noncritical,
normal,
low noncritical,
low critical,
low nonrecoverable)
04h CPU2 Vcore 05: Chassis Intrusion Voltage = Data × 0.008
05h 3.3V 06: Platform Security Breach Voltage = Data × 0.016
06h 5V 07: Processor Voltage = Data × 0.024
07h 12V 08: Power Supply Voltage = Data × 0.096
08h –12V 09: Power Unit Voltage = Data × 0.148 – 16.92
09h 1.5V 0A: Cooling Device Voltage = Data × 0.016
0Ah 5VSB 0C: Memory Voltage = Data × 0.024
0Bh VBAT 0D: Drive Slot Voltage = Data × 0.016
0Ch Fan1 0F: POST Error RPM = 1,350,000 ÷ Data
0Dh Fan2 — RPM = 1,350,000 ÷ Data
0Eh Fan3 — RPM = 1,350,000 ÷ Data
0Fh Fan4 — RPM = 1,350,000 ÷ Data
10h Fan5 — RPM = 1,350,000 ÷ Data
11h Fan6 — RPM = 1,350,000 ÷ Data
12h Fan7/CPU1 — RPM = 1,350,000 ÷ Data
13h Fan8/CPU2 — RPM = 1,350,000 ÷ Data
14h Power Supply — 1 (healthy) or 0 PSU health warning
44h Intrusion — 1 (intrusion) or 0 Intrusion alert
