Advanced menu
53
Voltage Readings The following voltage readings are displayed:
CPU1 Vcore, CPU2 Vcore, CPU1 Vtt, CPU2 Vtt, CPU1 DIMM, CPU2 DIMM, 1.1V, 1.5V,
1.8V, 3.3V, 12V, 5V, 3.3 Vsb, and VBAT.
Table 50. Hardware Health Monitor submenu (Continued)
BIOS item Usage
CPU1 /CPU2 Tcontrol Min
S
y
stem Tem
p
Min
CPU1/CPU2 Tcontrol Max
System Temp Max
Overheat
Alarm
CPU1/CPU2/SYS
Fan Speed Min
CPU1/CPU2/SYS
Fan Speed Max
CPU PECI
Count or
Temp (°C)
Fan PWM
