RAL STAINER User guide
12.3 ACTIVATED CARBON FILTER
The RAL Stainer recommends the changes of the activated carbon filter cartridges.
The life span is calculated using the RAL Stainer operating times.
RAL Stainer will give you an advertising message before the necessity of the filter-cartridge change: "The
activated carbon filter has expired: have you replaced it?"
The filter-cartridges are housed on the left of the machine.
1. Open the cover lid
2. Unscrew the two screws by a quarter turn
3. Remove the used filter cartridge
4. Fit a new filter-cartridge
5. Re-screw the two screws by a quarter turn
d. On page
,
MAINTENANCE
.
e. Switch on the rinsing pump in order to decontaminate the
rinsing circuit :
H2O
.
Switch off the rinsing pump by pressing
H2O
again.
Be careful, pump doesn’t stop automatically.
Fill the rinsing tank until to have the level at 1 cm from the rim.
f. Clean the waste circuit by switching on the draining pump,
, and press again this touch when the tank
is empty in order to switch off the pump.
Repeat at least 3 times steps “e” and “f” in order to decontaminate perfectly the waste circuit.
g. Rinse the rinsing liquid container with your rinsing solution.
h. Deep now the rinsing cane in the rinsing solution.
Repeat again by 3 times (at least) steps “e” and “f” with the rinsing solution of staining in order to eliminate
the disinfectant solution previously used.
H2O
NS
- +
- +
- +
- +
6
T1
T2
T3
T4
C1
C2
C3
C4
L1
L2
V
R
erase
trace
erase
mem
6. On page , set the cartridge life span counter to zero by pressing RAZ
RAL Stainer filter cartridges are available from your RAL Diagnostics reseller.
RAL STAINER
PROFILES
INIT
INFO
REAGENT KIT INFORMATION
Loaded kit : ---
Remaining cycles : 0
MACHINE INFORMATIONS
Serial number: 0000 20/02/2012 15:09:31
Software version : 02:41 / 02:14 / V305
Filter autonomy : 61h
PROFILES
Current session : XXX
